Image Sensor: 1/2.8' 4K Exmor CMOS
Effective Picture Elements: 8 Megapixels
Output Resolutions: 4K/30, 4K/29.97, 4K/25, 1080p/60, 1080p/59.94, 1080p/50, 1080p/30, 1080p/29.97, 1080p/25, 1080i/60, 1080i/59.94, 1080i/50, 720p/60, 720p/59.94, 720p/50
Minimum Illumination: 0.5 lux (IRE50, F1.6, 30fps)
S/N Ratio: = 50dB
Gain: Auto, Manual
TV Lines: 1400 (Center/Wide)
Shutter Speed: 1/1 to 1/32,000 sec
Exposure Control: Auto, Manual, Priority AE (Shutter, IRIS), BLC, WDR
White Balance: Auto, Manual, ATW, One Push
Optical Zoom: 12X
Digital Zoom: 12X
Total Zoom: 144X
Viewing Angles: DFOV : 78° (Wide) to 7° (Tele)
HFOV : 70° (Wide) to 6° (Tele): VFOV : 42° (Wide) to 3° (Tele)
Focal Length: f = 3.9 mm (Wide) to 46.8 mm (Tele)
Aperture (Iris): F = 1.6 (Wide) to 2.8 (Tele)
Minimum Working Distance: 0.3 m (Wide), 1.5m (Tele)
Pan / Tilt Angles: Pan : ±170°, Tilt : +90° / -30°
Pan / Tilt Speed (Manual): Pan : 0.1° to 100° /sec, Tilt : 0.1° to 100° /sec
Preset Speed: Pan : 200° /sec, Tilt : 200° /sec
Preset Positions: 10 (IR), 255 (RS-232, RS-422, IP)
Camera Control - Interfaces: RS-232 (DIN8), RS-422 (RJ45), IP
Camera Control - Protocols: VISCA (RS-232 / RS-422 / IP), PELCO-D & PELCO-P (RS-232 / RS-422), CGI (IP)
Image Processing: Noise Reduction (2D / 3D), Flip, Mirror
Power Frequencies: 50Hz, 60Hz
