Ceiling Mount



Chiefs FUSION™ Flat Panel Ceiling Mounts are installer inspired and offer perfect TV positioning and flexible adjustments for large flat panel screens. Great for digital signage installations.
•Ceiling Plate and extension column are required and must be ordered separately
•Compatible with traditional 1.5" NPT and new CPA pinned ceiling plates and column systems
•See ceiling plates and extension columns (Adjustable and Fixed) for 1.5" NPT compatibility
•See CPA ceiling plates and CPA columns for pin connection compatibility


Key Features
•REPEATABILITY
?Continuous tilt ranges with four set locking points to eliminate guess work when adjusting multiple screens.
•ACCESSIBILITY
?Simple on/off connection for ease of installation and service.
•CENTRIS® FINGERTIP TILT
?Effortlessly adjust display using Centris fingertip tilt technology.
•SIMPLE & SECURE
?Tool free screen engagement with optional padlock security.
•FLEXIBILITY
?Mount swivels to any preferred viewing angle.
•PORTRAIT
?FUSION™ rail is 400mm wide and the TV uprights reach patterns up to 800mm tall
•TAA Compliant

Spesifikasjoner

• Adjustments Roll, +/- 3°
• Certifications UL Listed, TAA Compliant
• Color Black
• Equipment Weight Capacity 125 lbs (56.7 kg)
• Mounting Pattern Compatibility (Universal Versions) 200 x 200mm - 400 x 800mm
• Number Of Monitors 1
• Orientation Portrait
• Shipping Weight 26 lbs
• Tilt --
• Weight Capacity 125 lbs (56.7 kg)
